WS160 | 2018-2022 120HP Turbo Models

What's Included?
~ DynoJet Power Vision PV3
~ WSRD Stock Injector Calibrations

WSRD Stock Injector Tune Files will come preloaded onto the Power Vision with installer ease.

Power Production:

• BRP Stock Tune; 120 Crank Horsepower
• WSRD WS160 Tune; 159 Hub Horsepower | 177 Crank Horsepower

Crack Pressure: (All WSRD Tunes require a crack pressure adjustment per fuel type.)

• WSRD WS160 Tune: 6 PSI

Not adjusting your crack pressure can result in underboost/overboost code scenarios. The WSRD Terminator Wastegate is not configured before shipping. After the supplied WSRD Terminator Wastegate is installed the crack pressure adjustment procedure will be REQUIRED. Please review the "WSRD Turbocharger Overview & Crack Pressure How-To Video | Can-Am X3" under the "WSRD Install Instructions" Tab found in our main menu or click the following link: https://www.youtube.com/watch?v=cpfTjqZohSY

Tune Features:

• Boost pressures are increase up to 14-15 PSI
• Crack pressure set to 6 PSI
• Radiator fan activation temp lowered from ~200* F to ~165* F
• Torque limits for L raised to 100%, reverse raised to 75%
• Component protection mode for fueling lowered to increase torque and horsepower, especially right after the pedal is floored.
• Ignition timing per cylinder is optimized for maximum power as well as drive-ability, careful consideration was used not only for when at wide open throttle, but as well as cruise, throttle transitions, ect.
• Throttle feel and control is thoughtfully improved, to control through a whoop section, on/off feel in short course style racing or playing in the woods, eco mode is improved but offers the less aggressive pedal for technical rock sections or simply loading on a trailer.
• Speed limits removed, your speed limit is your rev limiter/gear
• Rev limiter raised to 8900 RPM
• Rough road detection is raised to max to prevent power loss.
